Grandstream GWN7630 Wireless Access Point

Grandstream GWN7630 Wireless Access Point

Model: Grandstream GWN7630
Type: Indoor Dual-Band Enterprise Wireless Access Point

Wireless Specifications

• Wi-Fi Standard: IEEE 802.11 a/b/g/n/ac Wave 2
• Frequency Bands: 2.4 GHz & 5 GHz (Dual Band)
• MU-MIMO: 4×4:4 MU-MIMO
• Maximum Wireless Throughput: 2.33 Gbps
  • 2.4 GHz: Up to 600 Mbps
  • 5 GHz: Up to 1,733 Mbps
• Coverage Range: Up to 175 metres
• Concurrent Clients: Supports 200+ Wi-Fi devices
• SSIDs: Up to 32 SSIDs (16 per radio)

Network & Connectivity

• Ethernet Ports: 2 × 10/100/1000 Mbps Gigabit RJ45
• Power: PoE (IEEE 802.3af/802.3at) or DC Power Adapter
• Maximum Power Consumption: 16.5 W
• QoS: Advanced Quality of Service for voice and video applications

Security Features

• WPA/WPA2-PSK
• WPA/WPA2 Enterprise
• WPA3 Support
• WEP
• Secure Boot
• Digital Signature Protection
• Unique Security Certificate per Device
• Random Default Passwords

Management Features

• Embedded Controller for managing up to 50 local GWN Access Points
• Compatible with GDMS Networking cloud management
• Compatible with GWN Manager on-premise management
• Captive Portal
• VLAN Support
• Band Steering
• Load Balancing
• Fast Roaming
• Mesh Networking Support

Antenna

• 4 Internal Dual-Band Antennas
• 4×4:4 MU-MIMO Technology

Physical Specifications

• Installation: Ceiling or Wall Mount
• Dimensions: 205.3 × 205.3 × 45.9 mm
• Indoor Use
