Hp Elitedesk 800 G5 SFF 9th Generation 8GB 256GB SSD

Processor

• Model: Intel® Core™ i5-9500

• Cores/Threads: 6 cores / 6 threads

• Base Frequency: 3.0 GHz

• Max Turbo Frequency: Up to 4.4 GHz

• Cache: 9 MB SmartCache

• TDP: 65WPC ShopperHP Support

Memory

• Installed: 8GB DDR4-2666 MHz

• Slots: 4 DIMM slots (288-pin)

• Maximum Supported: Up to 128GB

Storage

• Primary Drive: 256GB PCIe NVMe M.2 SSD

• Expansion Options: Supports additional 2.5″ or 3.5″ SATA drives and M.2 SSDs

Graphics

• Integrated GPU: Intel UHD Graphics 630

• Discrete GPU Support: Optional low-profile GPUs (e.g., AMD Radeon RX 550, NVIDIA GeForce GT 730)

Connectivity & Ports

• USB Ports: 11 total

  • 1× USB 3.1 Gen2 Type-C

  • 4× USB 3.1 Gen2 Type-A

  • 2× USB 3.1 Gen1 Type-A

  • 4× USB 2.0 Type-A

• Video Outputs: 2× DisplayPort 1.2

• Optional Ports: Configurable with VGA, HDMI, USB-C with DisplayPort, or Thunderbolt 3

• Audio: Universal Audio Jack, Line-In, Line-Out

• Network: RJ-45 Gigabit Ethernet

Expansion Slots

• 1× PCIe 3.0 x16

• 1× PCIe 3.0 x16 (wired as x4)

• 2× PCIe 3.0 x1

• 2× M.2 slots for SSDs

• 1× M.2 slot for WLAN

Chassis & Power

• Form Factor: Small Form Factor (SFF)

• Dimensions: Approx. 338 × 308 × 100 mm

• Weight: Approx. 6.13 kg

• Power Supply: 180W or 250W 90% efficient PSU

Operating System

• Windows 10 Pro 64-bit (Upgradeable to Windows 11 Pro)

Security & Manageability

• BIOS Protection: HP Sure Start Gen5 (self-healing BIOS)

• Management Tools: HP Manageability Integration KitHP Support

---

Summary

• CPU: Intel Core i5-9500 (6 cores, up to 4.4 GHz)

• RAM: 8GB DDR4 (expandable to 128GB)

• Storage: 256GB NVMe SSD

• Graphics: Intel UHD 630

• Ports: 11× USB, 2× DisplayPort, optional HDMI/VGA/USB-C

• Expansion: Multiple PCIe and M.2 slots

• OS: Windows 10 Pro (Upgradeable to Windows 11 Pro)
