Hp Elitedesk 800 G5 SFF 9th Generation 8GB 500GB

Processor

• Model: Intel® Core™ i5-9500 (9th Generation)

• Cores/Threads: 6 Cores / 6 Threads

• Base Frequency: 3.0 GHz

• Max Turbo Boost: Up to 4.4 GHz

• Cache: 9 MB Intel® Smart Cache

• TDP: 65W

Memory

• Installed RAM: 8GB DDR4-2666 SDRAM

• Configuration: 1× 8GB module (1 slot used)

• Slots: 4 DIMM slots

• Maximum Capacity: Up to 128GB

Storage

• Drive Type: 3.5″ SATA HDD

• Capacity: 500GB

• Speed: 7200 RPM

• Expansion Support: M.2 SSD and additional 2.5″/3.5″ SATA drive

Graphics

• Integrated GPU: Intel® UHD Graphics 630

• Discrete GPU Support: Optional low-profile GPUs (e.g., AMD Radeon™, NVIDIA® GeForce®)

I/O Ports

Front Ports:

• 1× USB 3.1 Gen2 Type-C

• 1× USB 3.1 Gen2 Type-A

• 2× USB 3.1 Gen1 Type-A

• 1× Headphone/Microphone combo jack

Rear Ports:

• 4× USB 2.0 Type-A

• 2× USB 3.1 Gen1 Type-A

• 2× DisplayPort 1.2

• 1× Audio Line-In, Line-Out

• 1× RJ-45 Gigabit Ethernet

• Optional: VGA/HDMI/USB-C DisplayPort/Serial port

Expansion Slots

• 1× PCIe 3.0 x16

• 1× PCIe 3.0 x16 (wired as x4)

• 2× PCIe 3.0 x1

• 2× M.2 slots (1 for SSD, 1 for WLAN)

Networking

• Ethernet: Integrated Intel® I219LM Gigabit Ethernet

• Optional Wireless: M.2 slot for WLAN/BT module

Audio

• Integrated Realtek ALC3205 Audio Codec

• Internal speaker

Operating System

• Windows 10 Pro (Upgradable to Windows 11 Pro)

Security & Manageability

• TPM 2.0 (Firmware)

• HP Sure Start Gen5 (self-healing BIOS)

• HP Manageability Integration Kit

• Cable lock slot, chassis intrusion detection

Power Supply

• 180W or 250W 90% efficient PSU (varies by configuration)

Physical Specs

• Form Factor: Small Form Factor (SFF)

• Dimensions: 10.6″ x 3.7″ x 11.7″ (270 x 95 x 296 mm)

• Weight: ~6.1 kg (varies by configuration)
