Hikvision 10 CCTV Color Day with 16 Channel DVR Machine Ds 7100 series 300m cable

CCTV Cameras (10 Units – Color Day Cameras)

What’s in the package

• Brand: Hikvision (Turbo HD Series or equivalent)

• Type: Analog HD Bullet/Dome Cameras

• Resolution: 2MP (1920 x 1080 Full HD)

• Lens: 3.6mm Fixed Lens (Wide viewing angle ~82°)

• Image Sensor: 1/2.8” Progressive Scan CMOS

• Day/Night Function:

  • Color during day

  • IR at night (up to 20–30m)

• IR Cut Filter: True Day/Night with ICR

• Housing:

  • IP66/IP67 Weatherproof – suitable for indoor/outdoor

  • Vandal-resistant (optional dome models)

• Power Supply: 12V DC ±10%, Max ~4W per camera

---

DVR – Hikvision DS-7116HQHI-K1 (16-Channel DVR)

• Video Inputs: 16 BNC channels (supports up to 16 analog cameras)

• Video Output:

  • 1 HDMI (up to 1080p)

  • 1 VGA

• Video Compression: H.265 Pro+/H.265 Pro/H.265/H.264+/H.264

• Max Recording Resolution: 1080p Full HD

• Playback:

  • Synchronous playback: Up to 16 channels

  • Smart search, event search, motion detection playback

• Audio:

  • 1–4 audio input channels (RCA, model dependent)

  • 1 audio output

• Storage:

  • 1–2 SATA interfaces (up to 6TB each)

  • Typically includes 1TB–4TB HDD (optional)

• USB Ports: 2 × USB 2.0

• Network:

  • 1 RJ-45 Ethernet (10/100 Mbps)

  • Remote access via Hik-Connect App (iOS/Android)

  • Supports DDNS, FTP, NTP, SMTP

• Power Supply: 12V DC / 2A

• User Interface: Mouse, USB backup, on-screen menu

---

300m CCTV Combo Cable

• Type: RG59 Coaxial + DC Power Combo Cable (2-in-1)

• Length: 300 meters total (can be divided among 10 cameras)

• Connectors:

  • BNC for video

  • DC jack for power

• Cable Quality:

  • Shielded coaxial for clean signal

  • Weatherproof & UV-resistant for outdoor use

  • Stable signal up to 200 meters

---
